Extreme Networks 10320 Compatible 40GBASE-LR4 QSFP+ 40G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
Extreme Networks 10320 Compatible 40GBASE-LR4 QSFP+ 40G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
Extreme Networks 10320 Compatible 40GBASE-LR4 QSFP+ 40G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
P/N: QSFP-40G-LR4
US$107.00
8
Solds
2
Reviews
3
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1000 In Stock）

Product Highlights

Max Power Consumption < 3.5W
Complies with Class 1 FDA Laser Safety Standards
Supports Digital Diagnostic Monitoring Functionality
Compliant with Hot Pluggable QSFP+ MSA, IEEE802.3ba Standard
Compliant with RoHS Environmental Protection Standards (Lead-Free)
Provide Compatibility Test Reports for Multiple Brand Switches
See more
Specifications
Q&A
Reviews
Resources
Extreme Networks 10320 Compatible 40GBASE-LR4 QSFP+ 40G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
The 40G-QSFP-LR4 is a high-performance transceiver module designed for long-range optical communication applications, supporting transmission distances of up to 10 kilometers. It complies with the IEEE P802.3ba 40GBASE-LR4 standard, ensuring reliable and efficient data transmission. The module converts four input channels of 10Gb/s electrical data into four CWDM optical signals, which are then multiplexed into a single channel for 40Gb/s optical transmission. On the receiver side, it de-multiplexes a 40Gb/s optical input into four CWDM channels and converts them back into four channels of electrical data.
Specifications
Form Factor
10320
Max Data Rate
41.2Gbps
Wavelength
1310nm
Max Cable Distance
10km
Media
SMF
Connector
Duplex LC
Transmitter Type
DFB
Receiver Type
PIN
TX Power
-7~2.3dBm
Receiver Sensitivity
<-11dBm
Electrical Modulation
4x10.3125Gb/s NRZ
Optical Modulation
4x10.3125Gb/s NRZ
Power Consumption
≤3.5W
CBit Error Ratio (BER)
1.00E-12
Temperature Range
0 to 70°C (32 to 158°F)
Operating Relative Humidity
5%～85%
Host FEC
Supported
DDM/DOM
Supported
Protocols
40G Ethernet, SATA/SAS3, IEEE 802.3ba, MSA Compliant
Main application environments
40G Ethernet, Breakout to 10GBASE-SR Ethernet, Proprietary interconnections
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Questions & Answers
edit icon Ask a question
All (3) Management (1)Compatibility (1)Installation (1)
Q:

Can these be used in harsh environments?

by H***m on 2025-07-22 08:53:20

A:

We offer industrial-grade models for rugged applications.

by CPLIGHT on 2025-07-22 09:35:04

like icon Helpful 0
comment icon Comment 0
Q:

What should I do if there is no signal?

by y***m on 2025-07-22 08:14:10

A:

Check polarity, cleanliness, and compatibility first.

by CPLIGHT on 2025-07-22 09:34:28

like icon Helpful 0
comment icon Comment 0
Q:

Do I need to configure anything before installation?

by O***m on 2025-07-22 08:12:33

A:

No major configuration is required; most modules are plug-and-play.

by CPLIGHT on 2025-07-22 09:35:26

like icon Helpful 0
comment icon Comment 0
Customer Reviews
edit icon Write a review
All (2) Compatibility (1)Customer Support (1)
g
g***m
2025-06-27 14:38:42
Confirmed Purchase
5.0

Our core switches from Huawei and Arista detected the optics instantly. Compatibility is on par with the big-name brands, but at a fraction of the cost.

link icon Helpful 0
comment icon Comment 0
v
v***m
2025-05-13 03:18:06
Confirmed Purchase
5.0

We had a question about DOM support, and the vendor provided full documentation within hours, including screenshots and test results.

link icon Helpful 0
comment icon Comment 0
