- NVIDIA MMS4C11-XM800(980-9IAY1-00XM00) COMPATIBLE
800G DR4 OSFP224 Flat Top PAM4 1310nm 500m DOM MTP/MTP/MPO-12 APC Optical Transceiver Module
P/N: OSFP-800G-DR4 SKU: 20801
US$899.00
Transceiver Models:
- OSFP-1.6T-2DR4 1310nm 500m
- OSFP-1.6T-2FR4 1310nm 2km
- OSFP-800G-DR4 1310nm 500m
Compatible Brands:
MSA Standard
NVIDIA(InfiniBand)
Length:
500m
Quantity:
-
30-day return and refund
-
3-year warranty
-
Available for delivery within 2 days
-
Free shipping for orders over
Products Highlight
- Up to 800Gbps Aggregate Throughput
- Built-in Broadcom 3nm DSP Chip
- Low Power Consumption 16W
- SiPh-Based High-Density Design
- NVIDIA ConnectX-8 Fully Compatible
- OSFP MSA, CMIS, RoHS Compliant
Specifications
| Form Factor | OSFP224(Flat Top) | Data Rate | 850Gbps |
|---|---|---|---|
| Media | SMF | Wavelength | 1310nm |
| Connector | MTP/MPO-12 APC | Distance | 500m |
| Transmitter Type | EML | Receiver Type | PIN |
| Electrical Modulation | 4x 212.5G PAM4 | Optical Modulation | 4x 212.5G PAM4 |
| Power Consumption | ≤15.0W | Case Operating Temperature | 0 to 70°C (32 to 158°F) |
| Protocol | 800 Gigabit Ethernet 800G RoCE | Application | NIC to Switch NIC to NIC Other Optical Links |
Applications
Certification
Features
Switch Series & Supported Models
Browse common switch series and models supported for each brand.
| Series | Compatible Switch Models (Examples) |
|---|---|
| ConnectX-8 | C8180 (900-9X81E-00EX-ST0)C8180 (900-9X81E-00EX-DT0)C8180L (900-9X81E-00EX-SL0)C8280Z (900-9X86E-00CX-ST0) |
Compare Items
| 800G DR4 OSFP224 Flat Top PAM4 1310nm 500m DOM MTP/MTP/MPO-12 APC Optical Transceiver Module |  1.6T 2xDR4/DR8 OSFP224 Finned Top PAM4 1310nm 500m DOM Dual MTP/MPO-12 APC Optical Transceiver Module |  1.6T 2xFR4/FR8 OSFP224 Finned Top PAM4 1310nm 2km DOM Dual LC Duplex Optical Transceiver Module | |
|---|---|---|---|
| Form Factor | OSFP224(Flat Top) | OSFP224(Finned Top) | OSFP224(Finned Top) |
| Data Rate | 850Gbps | 1700Gbps | 1700Gbps |
| Connector | MTP/MPO-12 APC | Dual MTP/MPO-12 APC | Dual Duplex LC UPC |
| Distance | 500m | 500m | 2km |
| Electrical Modulation | 4x 212.5G PAM4 | 8x 212.5G PAM4 | 8x 212.5G PAM4 |
| Optical Modulation | 4x 212.5G PAM4 | Dual 4x 212.5G PAM4 | Dual 4x 212.5G PAM4 |
| Power Consumption | ≤15.0W | ≤25.0W | ≤26.0W |
Resources
FAQ
Ask a QuestionFind answers to common questions about our products.
How does this module differ from the 800G 2xDR4 OSFP module?
OSFP-800G-DR4 is single-port 4×212.5G PAM4, while 2xDR4 is dual-port 8×106.25G PAM4. Single-port modules are used on NICs to connect 1.6T switches; dual-port modules are mainly used on switches to connect 400G NICs.
Can this module be directly used in an 800G switch?
No. This is a Flat Top design. Switch ports generally require Finned Top modules to ensure thermal performance and compatibility.
