RG-S5750C-48GT4XS-H, Enterprise-Class Core/Aggregation Switch, 48 x GE Electrical Ports, Two Expansion Slots, 10GE Uplink
RG-S5750C-48GT4XS-H, Enterprise-Class Core/Aggregation Switch, 48 x GE Electrical Ports, Two Expansion Slots, 10GE Uplink
RG-S5750C-48GT4XS-H, Enterprise-Class Core/Aggregation Switch, 48 x GE Electrical Ports, Two Expansion Slots, 10GE Uplink
P/N: RG-S5750C-48GT4XS-H
Price Upon Request
9
Solds
3
Reviews
2
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1000 In Stock）

Product Highlights

Rich port types, 48 x 1000 Mbps Ethernet ports, 4 x 10GE optical ports for uplink
VSU virtualization, flexible networking and high performance
Effortless adaptation for multiple services with seamless Layer 3 routing functionality, ensuring efficient and reliable data transmission
Network security policies and real-time monitoring, delivering enhanced network robustness
Multiple management modes, simplified and easy network maintenance
See more
Specifications
Q&A
Reviews
Resources
RG-S5750C-48GT4XS-H, Enterprise-Class Core/Aggregation Switch, 48 x GE Electrical Ports, Two Expansion Slots, 10GE Uplink
Applied to the aggregation layer of large networks, the core of small and medium-sized networks, the access of server clusters, and the full Gigabit three-layer access of large enterprises or campus office buildings
Specifications
Product Model
RG-S5750C-48GT4XS-H
GE RJ45 port
48
GE SFP port
n/a
10GE SFP+ port
4
Card slot
2
Card type
1-port QSFP+ dedicated stack card 4-port 10GE SFP+ interface card
ETH management port
1
Console port (RJ45)
1
Console port (Mini USB)
1
USB 2.0 port
1
Switching capacity
256 Gbps
Packet forwarding rate
192 Mpps
MAC table size
64,000
ARP table size
20,000
Jumbo frame
9216 Bytes
Packet buffer
32Mbit
Maximum PoE power budget
n/a
PoE/PoE+ enabled port
n/a
Standard
n/a
Dimensions(WxDxH)
440 X 300 X 44mm
Unit weight
4.2kg
CPU
1GHz qual-core processor
Storage
DDR4 1 GB; 512MB Flash Memory
Data packet buffer
4MB
Type
Hot swappable
Redundancy
1+1
AC frequency
50/60Hz
Rated AC voltage
100~240V
Maximum AC voltage
90~264V
Rated HVDC voltage
240V DC
Maximum HVDC voltage
192~288V DC
Rated DC voltage
-36V ~ -72V DC
Maximum power rating
140W
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Questions & Answers
edit icon Ask a question
All (2) Performance (1)Scalability (1)
Q:

Can campus switches support future network growth?

by L***m on 2025-07-18 15:23:16

A:

Yes, many campus switches support stacking, modular expansion, and flexible port configurations to accommodate network growth and evolving bandwidth needs.

by Helpful on 2025-07-18 16:53:54

like icon Helpful 0
comment icon Comment 0
Q:

Are the switches easy to manage and monitor?

by O***m on 2025-07-18 15:21:03

A:

Yes. They typically offer centralized management options via SNMP, web GUI, CLI, or integration with network management systems for simplified monitoring and configuration.

by Helpful on 2025-07-18 16:54:48

like icon Helpful 0
comment icon Comment 0
Customer Reviews
edit icon Write a review
All (3) Performance (1)Ease of Use (1)Security (1)
Y
Y***m
2025-07-08 00:56:12
Confirmed Purchase
5.0

The built-in access control and port security made it easy to enforce our internal policies without complex configurations.

link icon Helpful 0
comment icon Comment 0
7
7***m
2025-05-08 03:14:57
Confirmed Purchase
5.0

The management interface is clean and user-friendly. Even with minimal IT staff, we were able to deploy and manage everything smoothly.

link icon Helpful 0
comment icon Comment 0
k
k***m
2025-04-19 10:18:17
Confirmed Purchase
5.0

We noticed a major improvement in network performance after upgrading to campus-grade switches — seamless connectivity across departments.

link icon Helpful 0
comment icon Comment 0
