Netgear 49Y7884 Compatible 40GBASE-SR4 QSFP+ 40G 850nm 100m DOM MTP/MPO-12 UPC MMF Ethernet Optical Transceiver Module
Netgear 49Y7884 Compatible 40GBASE-SR4 QSFP+ 40G 850nm 100m DOM MTP/MPO-12 UPC MMF Ethernet Optical Transceiver Module
Netgear 49Y7884 Compatible 40GBASE-SR4 QSFP+ 40G 850nm 100m DOM MTP/MPO-12 UPC MMF Ethernet Optical Transceiver Module
P/N: QSFP-40G-SR4
$23.00
5
Solds
5
Reviews
4
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1 In Stock）

Product Highlights

Max Power Consumption < 1.5W
Complies with Class 1 FDA Laser Safety Standards
Supports Digital Diagnostic Monitoring Functionality
Compliant with Hot Pluggable QSFP+ MSA, IEEE802.3ba Standard
Compliant with RoHS Environmental Protection Standards (Lead-Free)
Provide Compatibility Test Reports for Multiple Brand Switches
See more
Specifications
Certification
Connectivity Solutions
Comparison Table
Q&A
Reviews
Resources
Netgear 49Y7884 Compatible 40GBASE-SR4 QSFP+ 40G 850nm 100m DOM MTP/MPO-12 UPC MMF Ethernet Optical Transceiver Module
The 40G-QSFP-SR4 transceiver is a high-performance, parallel 40Gb/s QSFP+ optical module designed for high-speed data transmission. It integrates four independent transmitters and receivers, utilizing a four-channel 850nm VCSEL array, PIN array, amplifier, and driver to achieve compact size, low power consumption, and cost efficiency. Each channel supports data rates of up to 10Gbps, enabling transmission distances of up to 100 meters over OM3 multimode fiber. This makes the module ideal for high-density, short-range applications such as data center interconnects and high-performance computing.
Specifications
Form Factor
QSFP+
Data Rate
41.25Gbps
Media
MMF
Wavelength
850nm
Connector
MTP/MPO-12 UPC
Distance
100m@OM3 150m@OM4
Transmitter Type
VCSEL
Receiver Type
PIN
Electrical Modulation
4x 10.3125G NRZ
Optical Modulation
4x 10.3125G NRZ
Power Consumption
≤1.5W
Case Operating Temperature
0 to 70°C (32 to 158°F)
Protocol
40 Gigabit Ethernet 4x 10G Breakout Ethernet
Application
Swicth to Switch Switch to NIC Router to NIC Other Optical Links
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Connectivity Solutions
Netgear Switch links：25G SFP28 to 25G SFP28
All
Netgear Switch links：25G SFP28 to 25G SFP28
Comparison Table
Cisco Compatible 40GBASE-SR4 QSFP+40G 850nm 100m DOM MTP/MPO-12 UPC MMF Transceiver Module
QSFP-40G-SR4
Cisco Meraki Compatible 40GBASE-LR4 QSFP+ 40G 1310nm 10km DOM LC SMF Transceiver Module
QSFP-40G-LR4
Form Factor QSFP+QSFP+
Data Rate 41.25Gbps44.8Gbps
Media MMFSMF
Wavelength 850nm1264.5~1277.5nm@Lane 0 1284.5~1297.5nm@Lane 1 1304.5~1317.5nm@Lane 2 1324.5~1337.5nm@Lane 3
Connector MTP/MPO-12 UPCDuplex LC UPC
Distance 100m@OM3 150m@OM410km
Transmitter Type VCSELDFB
Receiver Type PINPIN
Electrical Modulation 4x 10.3125G NRZ4x 11.2G NRZ
Optical Modulation 4x 10.3125G NRZ4x 11.2G NRZ
Power Consumption ≤1.5W≤3.5W
Case Operating Temperature 0 to 70°C (32 to 158°F)0 to 70°C (32 to 158°F)
Protocol 40 Gigabit Ethernet 4x 10G Breakout Ethernet40 Gigabit Ethernet OTN OTU3
Application Swicth to Switch Switch to NIC Router to NIC Other Optical LinksSwicth to Switch OTN Equipment Other Optical Links
Form Factor
Data Rate
Media
Wavelength
Connector
Distance
Transmitter Type
Receiver Type
Electrical Modulation
Optical Modulation
Power Consumption
Case Operating Temperature
Protocol
Application
Cisco Compatible 40GBASE-SR4 QSFP+40G 850nm 100m DOM MTP/MPO-12 UPC MMF Transceiver Module
QSFP-40G-SR4
Cisco Meraki Compatible 40GBASE-LR4 QSFP+ 40G 1310nm 10km DOM LC SMF Transceiver Module
QSFP-40G-LR4
QSFP+
QSFP+
41.25Gbps
44.8Gbps
MMF
SMF
850nm
1264.5~1277.5nm@Lane 0 1284.5~1297.5nm@Lane 1 1304.5~1317.5nm@Lane 2 1324.5~1337.5nm@Lane 3
MTP/MPO-12 UPC
Duplex LC UPC
100m@OM3 150m@OM4
10km
VCSEL
DFB
PIN
PIN
4x 10.3125G NRZ
4x 11.2G NRZ
4x 10.3125G NRZ
4x 11.2G NRZ
≤1.5W
≤3.5W
0 to 70°C (32 to 158°F)
0 to 70°C (32 to 158°F)
40 Gigabit Ethernet 4x 10G Breakout Ethernet
40 Gigabit Ethernet OTN OTU3
Swicth to Switch Switch to NIC Router to NIC Other Optical Links
Swicth to Switch OTN Equipment Other Optical Links
Questions & Answers
edit icon Ask a question
All (4) Application (1)Product (1)Compatibility (2)
Q:

What fiber connectors are supported?

by Y***m on 2025-08-07 05:16:45

A:

We support LC, MPO, and MTP connectors based on the module type.

by AICPLIGHT on 2025-08-07 10:19:59

like icon Helpful 0
comment icon Comment 0
Q:

Can this cable be used for GPU interconnect?

by x***m on 2025-07-14 21:07:21

A:

Yes, especially our IB and AOC cables are ideal for GPU-to-GPU communication.

by AICPLIGHT on 2025-07-15 07:16:19

like icon Helpful 0
comment icon Comment 0
Q:

Can these transceivers auto-negotiate with older models?

by o***m on 2025-06-06 18:53:23

A:

Yes, backward compatibility is supported in many cases.

by AICPLIGHT on 2025-06-07 05:43:34

like icon Helpful 0
comment icon Comment 0
Q:

Can I request a test report for each batch?

by F***m on 2025-06-05 17:58:53

A:

Yes, test reports can be provided for all outgoing batches.

by AICPLIGHT on 2025-06-05 21:52:04

like icon Helpful 0
comment icon Comment 0
Customer Reviews
edit icon Write a review
All (5) Compatibility (1)Ease of Use (1)Customer Support (1)Value (2)
2
2***m
2025-08-02 17:19:29
Confirmed Purchase
5.0

No need for vendor-specific coding or configuration tools. These just worked out of the box, even in slightly older switches.

link icon Helpful 0
comment icon Comment 0
W
W***m
2025-07-07 01:28:55
Confirmed Purchase
5.0

A fantastic value for upgrading legacy 10G to modern 25G backbones. Performance is solid and pricing is highly competitive.

link icon Helpful 0
comment icon Comment 0
R
R***m
2025-06-16 22:13:19
Confirmed Purchase
5.0

We had a question about DOM support, and the vendor provided full documentation within hours, including screenshots and test results.

link icon Helpful 0
comment icon Comment 0
2
2***m
2025-06-16 10:20:53
Confirmed Purchase
5.0

A cost-effective solution for large campus and edge deployments, especially when managing hundreds of switch ports.

link icon Helpful 0
comment icon Comment 0
H
H***m
2025-05-10 13:31:48
Confirmed Purchase
5.0

These transceivers were immediately recognized by our Dell and HPE servers with no firmware complaints. It was a simple swap from our OEM modules.

link icon Helpful 0
comment icon Comment 0
