NVIDIA/Mellanox MMA2L20-AR Compatible 25GBASE-LR SFP28 25G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module

P/N: SFP-25G-LR

US$29.00

Solds

Reviews

Questions

4-Year Warranty

30-Day Returns

30-Day Exchange

（1000 In Stock）

Product Highlights

Built-in Macom Chip, Max. Power Consumption 1.2W

Interoperable with Other IEEE-compliant 25G Interfaces for Seamless Integration

Tested in Targeted Switch for Superior Performance, Quality, and Reliability

High-speed Connectivity Compliant to IEEE 802.3by and IEEE 802.3cc

Applied in 25G Ethernet, Telecom, and Data Center

Hot Pluggable SFP28 MSA Compliant

Class 1 FDA Laser Safety and RoHS Compliant

Specifications

Q&A

Reviews

Resources

NVIDIA/Mellanox MMA2L20-AR Compatible 25GBASE-LR SFP28 25G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module

The SFP-25G-LR SFP28 transceiver provides 25GBase-LR throughput up to 10km over single mode fiber (SMF) using a wavelength of 1310nm via an LC duplex connector. The SFP28 transceiver works on the same 10G network cabling Infrastructure, boosting speed by at least 2.5 times. It also features DDM/DOM for real-time monitoring of operating status. This hot-swappable transceiver is pre-programmed, uniquely serialized, and tested for data traffic and application performance. Besides, it offers interoperability, laying a foundation for the next-generation network upgrade. Each SFP28 transceiver module is individually tested in targeted switch, it is fully compliant with the SFP28 MSA, CPRI and eCPRI standard. Featuring low power consumption, high speed, this 25G transceiver is ideal for 25G Ethernet, telecom, and data center.

Specifications

Part Number

MMA2L20-AR

Vendor Name

AICPLIGHT

Form Factor

SFP28

Max Data Rate

25.78Gbps

Wavelength

1310nm

Max Cable Distance

10km

Connector

Duplex LC

Media

SMF

Transmitter Type

DFB 1310nm

Receiver Type

TX Power

-4~2dBm

Minimum Receiver Power

<-12dBm

Power Budget

8dB

Receiver Overload

2dBm

Power Consumption

≤1.2W

Extinction Ratio

3.5dB

CDR (Clock and Data Recovery)

TX & RX

Inbuilt FEC

Yes

Commercial Temperature Range

0 to 70°C (32 to 158°F)

DDM/DOM

Supported

Core Size

G.652

Packaging Technology

BOX Packaging

Protocols

MSA Compliant, CPRI, eCPRI

Warranty

5 Years

Certification
