NVIDIA/Mellanox Compatible 400GBASE-SR4 QSFP-DD PAM4 850nm 100m DOM MPO-12/APC MMF Ethernet Optical Transceiver Module, Breakout to 2 x 200G-SR and 4 x 100G-SR
P/N: QDD-400G-SR4
US$2800.00
4-Year Warranty
30-Day Returns
30-Day Exchange

Product Highlights

Built-in Maxlinear Chip, Max. Power Consumption 8W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
Compliant with QSFP-DD MSA, CMIS Rev5.2
Hot Pluggable QSFP-DD Form Factor
High-speed Electrical Compliant to IEEE802.3bs
8x 50G PAM4 Retimed 400GAUI-8 Electrical Interface
QSFP-DD Port is Backward Compatible with QSFP+, QSFP28 and QSFP56 Modules
See more
Specifications
Q&A
Reviews
Resources
NVIDIA/Mellanox Compatible 400GBASE-SR4 QSFP-DD PAM4 850nm 100m DOM MPO-12/APC MMF Ethernet Optical Transceiver Module, Breakout to 2 x 200G-SR and 4 x 100G-SR
The 400GBASE-SR4 module, MTP/MPO-12 connector, up to 100m over parallel OM4 multi-mode fiber. It is compliant to IEEE 802.3bs protocol and 400GAUI-8 standard.The 400 Gigabit Ethernet signal is carried over four parallel lanes by one wavelength per lane. It can support 2 x 200G-SR and 4 x 100G-SR.
Specifications
Part Number
QDD-400G-SR4
Vendor Name
CPLIGHT
Form Factor
QSFP-DD
Max Data Rate
400Gbps
Wavelength
850nm
Max Cable Distance
60m@OM3/100m@OM4
Connector
MTP/MPO-12 (APC)
Media
MMF
Transmitter Type
VCSEL 850nm
Receiver Type
PIN
TX Power
-4.6~4dBm
RX Power
-6.3~4dBm
Max Power Consumption
8W
Extinction Ratio
2.5dB
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Modulation (Electrical)
4x100G-PAM4
Modulation (Optical)
8x50G-PAM4
CDR (Clock and Data Recovery)
TX & RX
Inbuilt FEC
Yes
Core Size
50/125µm
Packaging Technology
COB
Protocols
IEEE 802.3bs, QSFP-DD MSA, IEEE 802.3db,CMIS rev 5.2
Warranty
5 Years
Certification
Features
