MSA Standard Compatible 10GBASE-LR SFP+ 10G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
MSA Standard Compatible 10GBASE-LR SFP+ 10G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
MSA Standard Compatible 10GBASE-LR SFP+ 10G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
P/N: SFP-10G-LR
US$11.90
1
Solds
2
Reviews
4
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1000 In Stock）

Product Highlights

Built-in Semtech Chip, Max. Power Consumption 1W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
Hot Pluggable SFP+ MSA Compliant
Optical Interoperability with 10GBASE XENPAK, X2, and XFP Interfaces On the Same Link
TO Package Features High Reliability and Robust Physical Protection
Class 1 FDA Laser Safety and RoHS Compliant
IEEE 802.3ae Compliant
See more
Specifications
Q&A
Reviews
Resources
MSA Standard Compatible 10GBASE-LR SFP+ 10G 1310nm 10km DOM Duplex LC/UPC SMF Ethernet Optical Transceiver Module
The SFP-10G-LR SFP+ transceiver supports up to 10km link lengths over LC duplex SMF fiber. This transceiver is compliant with SFF-8431, SFF-8432 and IEEE 802.3ae standards. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Featuring low power consumption, high speed, this 10G SFP+ transceiver is ideal for data center, enterprise wiring closet, service provider transport application, Radio & Baseband Unit, etc.
Specifications
Part Number
SFP-10G-LR
Vendor Name
AICPLIGHT
Form Factor
SFP+
Max Data Rate
10.3125Gbps
Wavelength
1310nm
Max Cable Distance
10km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
PIN
TX Power
-8.2~0.5dBm
Receiver Sensitivity
< -14.4dBm
Power Budget
6.2dB
Receiver Overload
0.5dBm
Typical Power Consumption
≤1W
Extinction Ratio
>3.5dB
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Core Size
9/125µm
Modulation
NRZ
Protocols
IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Questions & Answers
edit icon Ask a question
All (4) Application (1)Product (1)Installation (1)Performance (1)
Q:

Can this cable be used for GPU interconnect?

by G***m on 2025-06-27 15:21:37

A:

Yes, especially our IB and AOC cables are ideal for GPU-to-GPU communication.

by AICPLIGHT on 2025-06-27 17:41:50

like icon Helpful 0
comment icon Comment 0
Q:

Are installation tools provided?

by h***m on 2025-06-18 10:03:16

A:

We provide installation guidance and optional tool kits.

by AICPLIGHT on 2025-06-18 16:01:05

like icon Helpful 0
comment icon Comment 0
Q:

Do you offer custom labeling or OEM branding?

by 6***m on 2025-05-23 10:38:38

A:

Yes, OEM branding and custom labeling are available upon request.

by AICPLIGHT on 2025-05-23 19:28:30

like icon Helpful 0
comment icon Comment 0
Q:

What’s the typical BER (Bit Error Rate)?

by I***m on 2025-05-21 15:03:58

A:

Typical BER is under normal operation.

by AICPLIGHT on 2025-05-21 18:04:27

like icon Helpful 0
comment icon Comment 0
Customer Reviews
edit icon Write a review
All (2) Customer Support (1)Value (1)
E
E***m
2025-08-14 23:55:07
Confirmed Purchase
5.0

Allowed us to expand port capacity without blowing the budget. Ideal for mid-sized IT teams and MSPs.

link icon Helpful 0
comment icon Comment 0
L
L***m
2025-06-09 20:16:56
Confirmed Purchase
5.0

We had a question about DOM support, and the vendor provided full documentation within hours, including screenshots and test results.

link icon Helpful 0
comment icon Comment 0
