NVIDIA Mellanox 900-9D3B6-00SV-AA0 BlueField-3 InfiniBand & Ethernet Adapter Card 200GbE/NDR200, Dual-Port QSFP112, PCIe 5.0 x 16, with x 16 PCIe Extension Option, Tall&Short Bracket
NVIDIA Mellanox 900-9D3B6-00SV-AA0 BlueField-3 InfiniBand & Ethernet Adapter Card 200GbE/NDR200, Dual-Port QSFP112, PCIe 5.0 x 16, with x 16 PCIe Extension Option, Tall&Short Bracket
NVIDIA Mellanox 900-9D3B6-00SV-AA0 BlueField-3 InfiniBand & Ethernet Adapter Card 200GbE/NDR200, Dual-Port QSFP112, PCIe 5.0 x 16, with x 16 PCIe Extension Option, Tall&Short Bracket
P/N: 900-9D3B6-00SV-AA0
Price Upon Request
6
Solds
1
Reviews
3
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1000 In Stock）

Product Highlights

Delivering Up to 200Gb/s Ethernet and InfiniBand Connectivity for Both Traditional Applications and Modern Workloads
Providing Powerful Computing with 16 Arm Cores and a Broad Range of Programmable Acceleration Engines
Boosts AI Performance with RoCE Networking, GPUDirect® RDMA, Direct Data Placement, and Congestion Control for an Efficient Network
Enables a Zero-trust, Security-everywhere Architecture that Extends Beyond the Data Center to Every Server's Edge
NVMe over Fabrics, GPUDirect Storage, and Advanced Features Enable High-performance Storage Access
Specifications
Q&A
Reviews
Resources
NVIDIA Mellanox 900-9D3B6-00SV-AA0 BlueField-3 InfiniBand & Ethernet Adapter Card 200GbE/NDR200, Dual-Port QSFP112, PCIe 5.0 x 16, with x 16 PCIe Extension Option, Tall&Short Bracket
The NVIDIA BlueField-3 DPU is an infrastructure compute platform that enables line-rate processing of software-defined networking, storage, and cybersecurity. BlueField-3 combines powerful computing, high-speed networking, and extensive programmability to deliver software-defined, hardware-accelerated solutions for the most demanding workloads. From accelerated AI to hybrid cloud, high-performance computing to 5G wireless networks, BlueField-3 redefines the art of the possible.
Specifications
Brand
Nvidia
Technology
VPI
Ports
Dual-Port QSFP112
Interface
PCIe 5.0 x16
Controller
BlueField-3
Data Rate
(IB) NDR200/HDR/HDR100/EDR/FDR/SDR (Eth) 200/100/50/25/10 Gb/s
OS Support
Debian, Oracle Linux, RHEL/CentOS, Ubuntu
SR-IOV
Yes
FHHL Card Dimensions
4.37 in. x 6.60 in (111.15mm x 167.65mm)
Operating Temperature
0 to 55 °C (32 to 131 °F)
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Questions & Answers
edit icon Ask a question
All (3) Product (1)Compatibility (1)Scalability (1)
Q:

What is the function of the x16 PCIe extension option?

by c***m on 2025-03-26 08:09:40

A:

It allows external expansion for additional PCIe devices or for extending the compute or storage pipeline using the DPU.

by AICPLIGHT on 2025-03-26 19:03:51

like icon Helpful 0
comment icon Comment 0
Q:

Which systems and platforms support this adapter?

by Y***m on 2024-12-15 18:35:12

A:

It’s compatible with major server platforms that support PCIe Gen5 x16, including x86 and ARM architectures, and integrates with Linux distros.

by AICPLIGHT on 2024-12-15 19:42:02

like icon Helpful 0
comment icon Comment 0
Q:

What are the key capabilities of this BlueField-3 adapter card?

by b***m on 2024-12-03 19:37:52

A:

It supports 200GbE/NDR200 through dual-port QSFP112, PCIe 5.0 x16 interface, and includes an integrated DPU for offloading networking functions.

by AICPLIGHT on 2024-12-04 12:17:51

like icon Helpful 0
comment icon Comment 0
Customer Reviews
edit icon Write a review
All (1) Performance (1)
R
R***m
2025-06-24 21:04:51
Confirmed Purchase
5.0

We deployed this BlueField-3 adapter in our HPC cluster, and it drastically improved the data throughput and latency across compute nodes.
