RG-S6150-24VS8CQ-X, 24-Port 25GE, All-Optical, Layer 3, Managed Core & Aggregation Switch, 100G Uplink
RG-S6150-24VS8CQ-X, 24-Port 25GE, All-Optical, Layer 3, Managed Core & Aggregation Switch, 100G Uplink
RG-S6150-24VS8CQ-X, 24-Port 25GE, All-Optical, Layer 3, Managed Core & Aggregation Switch, 100G Uplink
P/N: RG-S6150-24VS8CQ-X
Price Upon Request
6
Solds
3
Reviews
2
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1000 In Stock）

Product Highlights

Rich port types, 24 x 1GE/10GE/25GE SFP28 ports, and 8 x 40GE/100GE QSFP28 ports for uplink
VSU virtualization, flexible networking and high performance
Hardware redundancy, guaranteed service continuity and network connectivity
Layer 3 routing control, adaptive to multiple services, efficient and guaranteed data transmission
Network security policies and real-time monitoring, delivering enhanced network robustness
Paired with INC for simplified and efficient O&M
See more
Specifications
Q&A
Reviews
Resources
RG-S6150-24VS8CQ-X, 24-Port 25GE, All-Optical, Layer 3, Managed Core & Aggregation Switch, 100G Uplink
Core or aggregation switch for small and medium-sized networks, supporting the smooth evolution to 25G campus networks
Specifications
Fixed service port
24 x 1GE/10GE/25GE SFP28 ports ;8 x 40GE/100GE QSFP28 ports
Port specifications
RG-S6150-24VS8CQ-X
Module slot
2 x power module slots ;4 x fan module slots
Fixed management port
1 x RJ45 console port ; 1 x RJ45 MGMT port
USB
1 x USB 2.0 port
System switching capacity *1
2.8 Tbps
CPU
Quad-core CPU, each core with the clock speed of 2.2 GHz
Real-time clock (RTC)
Supported
BootROM
16 MB
Flash memory
8 GB
Memory
4 GB DDR4
Switch buffer
35 MB
Number of MAC addresses
128,000 (default)
ARP table size
96,000 (default)
ND table size
80,000 (default)
Number of IPv4 unicast routes
350,000 (default)
Number of IPv4 multicast routes
4,000
Number of IPv6 unicast routes
65,000 (default)
Number of IPv6 multicast routes
2,000
Number of IGMP groups
4,000
Number of MLD groups
1,000
Number of VSU members
4
Number of VRFs
1,024
Power supply
2 x pluggable power modules
Maximum power consumption
270W
Rack height
1 RU
Shipping weight
9.65 kg (21.27 lbs)
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage temperature
–40°C to +70°C (–40°F to +158°F)
Operating Humidity
10% to 90% RH (non-condensing)
Storage humidity
5% to 95% RH (non-condensing)
Fan
4 x pluggable fan modules
Power module redundancy
1+1 redundancy
Fan redundancy
3+1 redundancy
Power module hot swapping
Supported
USB hot swapping
Supported
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Questions & Answers
edit icon Ask a question
All (2) Performance (1)Scalability (1)
Q:

Can campus switches support future network growth?

by 3***m on 2025-07-18 16:23:23

A:

Yes, many campus switches support stacking, modular expansion, and flexible port configurations to accommodate network growth and evolving bandwidth needs.

by CPLIGHT on 2025-07-18 16:53:54

like icon Helpful 0
comment icon Comment 0
Q:

Are the switches easy to manage and monitor?

by 3***m on 2025-07-18 15:25:59

A:

Yes. They typically offer centralized management options via SNMP, web GUI, CLI, or integration with network management systems for simplified monitoring and configuration.

by Helpful on 2025-07-18 16:54:48

like icon Helpful 0
comment icon Comment 0
Customer Reviews
edit icon Write a review
All (3) Performance (1)Ease of Use (1)Security (1)
G
G***m
2025-06-03 07:59:48
Confirmed Purchase
5.0

We noticed a major improvement in network performance after upgrading to campus-grade switches — seamless connectivity across departments.

link icon Helpful 0
comment icon Comment 0
K
K***m
2025-05-04 22:43:02
Confirmed Purchase
5.0

The built-in access control and port security made it easy to enforce our internal policies without complex configurations.

link icon Helpful 0
comment icon Comment 0
Q
Q***m
2025-04-11 03:23:56
Confirmed Purchase
5.0

The management interface is clean and user-friendly. Even with minimal IT staff, we were able to deploy and manage everything smoothly.

link icon Helpful 0
comment icon Comment 0
