NVIDIA/Mellanox Compatible 400GBASE-DR4 QSFP112 PAM4 1310nm 500m DOM MPO-12/APC SMF Optical Transceiver Module, Breakout to 4 x 100G-DR
NVIDIA/Mellanox Compatible 400GBASE-DR4 QSFP112 PAM4 1310nm 500m DOM MPO-12/APC SMF Optical Transceiver Module, Breakout to 4 x 100G-DR
NVIDIA/Mellanox Compatible 400GBASE-DR4 QSFP112 PAM4 1310nm 500m DOM MPO-12/APC SMF Optical Transceiver Module, Breakout to 4 x 100G-DR
P/N: Q112-400G-DR4
US$409.00
11
Reviews
4
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
（1000 In Stock）

Product Highlights

Built-in Macom Chip, Max. power consumption 10W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
Compliant with QSFP112 MSA CMIS Rev5.0
Hot-pluggable QSFP112 Form Factor
High-speed Electrical Compliant to IEEE 802.3ck
4x106.25G PAM4 Retimed 400GAUI-4 Electrical Interface
Interoperable with other IEEE-compliant 400GBASE interfaces where applicable
Class 1 Laser Safety
See more
Specifications
Q&A
Reviews
Resources
NVIDIA/Mellanox Compatible 400GBASE-DR4 QSFP112 PAM4 1310nm 500m DOM MPO-12/APC SMF Optical Transceiver Module, Breakout to 4 x 100G-DR
The 400GBASE-DR4 module, MTP/MPO-12 connector, up to 500m over parallel single-mode fiber. It is compliant with QSFP112 MSA, CMIS 5.0 Interface and 400GAUI-4 standards.
The built-in digital diagnostics monitoring (DDM) allows access to real-time operating parameters. It is suitable for 400G ethernet and data center interconnect applications.
Specifications
Part Number
Q112-400G-DR4
Vendor Name
AICPLIGHT
Form Factor
QSFP112
Max Data Rate
425Gbps (4x106.25Gb/s)
Wavelength
1310nm
Max Cable Distance
500m
Connector
MPO-12/APC
Media
SMF
Transmitter Type
EML
Receiver Type
PIN
TX Power
-2.9~4.0dBm
Minimum Receiver Power
-5.9dBm
Power Budget
3dB
Receiver Overload
4.0dBm
Max Power Consumption
10W
Extinction Ratio
＞3.5dB
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Modulation (Electrical)
4x100G-PAM4
Modulation (Optical)
4x100G-PAM4
CDR (Clock and Data Recovery)
TX & RX
Inbuilt FEC
No
Core Size
G.652/9um
Packaging Technology
COB
Protocols
IEEE Std 802.3ck, QSFP112 MSA, CMIS 5.0
Warranty
5 Years
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
Questions & Answers
edit icon Ask a question
All (4) Product (1)Installation (1)Performance (2)
Q:

Do these cables support 100Gbps per lane?

by b***m on 2025-07-08 13:56:43

A:

Yes, some models support up to 100Gbps/lane.

by CPLIGHT on 2025-07-08 14:48:55

like icon Helpful 0
comment icon Comment 0
Q:

Are installation tools provided?

by f***m on 2025-07-08 13:46:12

A:

We provide installation guidance and optional tool kits.

by Helpful on 2025-07-08 14:38:55

like icon Helpful 0
comment icon Comment 0
Q:

What’s the typical BER (Bit Error Rate)?

by 1***m on 2025-07-08 13:40:59

A:

Typical BER is under normal operation.

by CPLIGHT on 2025-07-08 14:49:47

like icon Helpful 0
comment icon Comment 0
Q:

What is the average power consumption of this transceiver?

by w***m on 2025-07-08 13:30:44

A:

The average power consumption varies by model, but it typically ranges between 3W to 12W.

by CPLIGHT on 2025-07-08 14:15:35

like icon Helpful 0
comment icon Comment 0
