H3C Compatible 400GBASE-SR4 QSFP112 PAM4 850nm 50m DOM MPO-12/APC MMF Optical Transceiver Module
P/N: Q112-400G-SR4
US$339.00
12
Reviews
7
Questions
safeguard
4-Year Warranty
30-Day Returns
30-Day Exchange
(1000 In Stock)

Product Highlights

Built-in Broadcom 7nm Chip, Max. Power Consumption 9W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
Compliant with QSFP112 MSA CMIS Rev4.0
Hot-pluggable QSFP112 Form Factor
High-speed Electrical Compliant to IEEE 802.3db
4x 106.25G PAM4 Retimed 400GAUI-4 Electrical Interface
Interoperable with other IEEE-compliant 400GBASE interfaces where applicable
Class 1 Laser Safety
See more
H3C Compatible 400GBASE-SR4 QSFP112 PAM4 850nm 50m DOM MPO-12/APC MMF Optical Transceiver Module
The 400GBASE-SR4 module, MTP/MPO-12 connector, up to 50m over parallel OM4 multi-mode fiber. It is compliant with QSFP112 MSA, CMIS 4.0 Interface and 400GAUI-4 standards.
The built-in digital diagnostics monitoring (DDM) allows access to real-time operating parameters. It is suitable for 400G ethernet and data center interconnect applications.
Specifications
Part Number
Q112-400G-SR4
Vendor Name
AICPLIGHT
Form Factor
QSFP112
Max Data Rate
425Gbps (4x106.25Gb/s)
Wavelength
850nm
Max Cable Distance
30m@OM3/50m@OM4
Connector
MPO-12 (APC)
Media
MMF
Transmitter Type
VCSEL
Receiver Type
PIN
TX Power
-4.6~4dBm
Minimum Receiver Power
-6.4dBm
Power Budget
1.8dB
Receiver Overload
4.0dBm
Max Power Consumption
9W
Extinction Ratio
>2.5dB
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Modulation (Electrical)
4x100G-PAM4
Modulation (Optical)
4x100G-PAM4
CDR (Clock and Data Recovery)
TX & RX
Inbuilt FEC
Yes
Protocols
IEEE Std 802.3db, QSFP112 MSA, CMIS 4.0
Warranty
5 Years
Certification
Product
Product
Product
Product
Product
Product
Product
Product
Product
Product
